How to Create Dynamic Multi Line Chart in Laravel 11
Hello, laravel web developers! In this article, we'll see how to create a dynamic multi line chart in laravel 11. In laravel 11, we'll use echart library to display dynamic multi line charts. A multi-line chart is a basic line chart with one or more additional lines that represent comparison trends.
Using this chart, you can easily compare the position, performance, or rankings of multiple observations to each other rather than the actual values themselves.
Laravel 11 Create Dynamic Multi Line Chart
In this step, we'll install the laravel 11 application using the following command.
composer create-project --prefer-dist laravel/laravel multi-line-chart
Next, we'll Configure your .env file with your database credentials.
DB_CONNECTION=mysql
DB_HOST=127.0.0.1
DB_PORT=3306
DB_DATABASE=your_database_name
DB_USERNAME=your_database_user
DB_PASSWORD=your_database_password
Then, create a migration using the following command.
php artisan make:migration create_data_points_table --create=data_points
Migration:
Schema::create('data_points', function (Blueprint $table) {
$table->id();
$table->string('name');
$table->integer('year');
$table->integer('value');
$table->timestamps();
});
Then, run the migrate the table into the database using the following command.
php artisan migrate
Next, we'll create a model and controller using the following command.
php artisan make:model DataPoint
Create a controller.
php artisan make:controller ChartController
app/Http/Controllers/ChartController.php
use App\Http\Controllers\Controller;
use Illuminate\Support\Facades\DB;
use App\Models\DataPoint;
class ChartController extends Controller
{
public function index()
{
$data = DataPoint::get();
$formattedData = $this->formatData($data);
return view('chart', compact('formattedData'));
}
private function formatData($data)
{
$result = [];
foreach ($data as $item) {
$result[$item->name][] = $item->value;
}
return $result;
}
}
Now, Define a route to the web.php file.
routes/web.php
use App\Http\Controllers\ChartController;
Route::get('/', [ChartController::class, 'index']);
Next, we'll create a blade view to display the dynamic chart.
resources/views/chart.blade.php
<!DOCTYPE html>
<html lang="en">
<head>
<meta charset="utf-8">
<title>Dynamic Multi Line Chart in Laravel 11 - Techsolutionstuff</title>
<style>
* {
margin: 0;
padding: 0;
}
#chart-container {
position: relative;
height: 100vh;
overflow: hidden;
}
</style>
</head>
<body>
<div id="chart-container"></div>
<script src="https://cdnjs.cloudflare.com/ajax/libs/jquery/3.7.1/jquery.min.js"></script>
<script src="https://fastly.jsdelivr.net/npm/echarts@5.5.1/dist/echarts.min.js"></script>
<script>
var dom = document.getElementById('chart-container');
var myChart = echarts.init(dom, null, {
renderer: 'canvas',
useDirtyRect: false
});
var app = {};
var option;
const names = [
'Orange',
'Tomato',
'Apple',
];
const years = ['2001', '2002', '2003', '2004', '2005', '2006'];
const formattedData = @json($formattedData);
const generateSeriesList = () => {
const seriesList = [];
for (const [name, data] of Object.entries(formattedData)) {
const series = {
name,
symbolSize: 20,
type: 'line',
smooth: true,
emphasis: {
focus: 'series'
},
endLabel: {
show: true,
formatter: '{a}',
distance: 20
},
lineStyle: {
width: 4
},
data
};
seriesList.push(series);
}
return seriesList;
};
option = {
title: {
text: 'Multi Line Chart'
},
tooltip: {
trigger: 'item'
},
grid: {
left: 30,
right: 110,
bottom: 30,
containLabel: true
},
toolbox: {
feature: {
saveAsImage: {}
}
},
xAxis: {
type: 'category',
splitLine: {
show: true
},
axisLabel: {
margin: 30,
fontSize: 16
},
boundaryGap: false,
data: years
},
yAxis: {
type: 'value',
axisLabel: {
margin: 30,
fontSize: 16,
formatter: '#{value}'
},
inverse: true,
interval: 1,
min: 1,
max: names.length
},
series: generateSeriesList()
};
if (option && typeof option === 'object') {
myChart.setOption(option);
}
window.addEventListener('resize', myChart.resize);
</script>
</body>
</html>
Next, we'll create a seeder for sample data using the following command.
php artisan make:seeder DataPointsSeeder
database/seeders/DataPointsSeeder.php
use Illuminate\Database\Seeder;
use Illuminate\Support\Facades\DB;
class DataPointsSeeder extends Seeder
{
public function run()
{
$names = ['Orange', 'Tomato', 'Apple'];
$years = range(2001, 2006);
foreach ($years as $year) {
foreach ($names as $name) {
DB::table('data_points')->insert([
'name' => $name,
'year' => $year,
'value' => rand(1, 3),
'created_at' => now(),
'updated_at' => now(),
]);
}
}
}
}
Run the seeder using the following command.
php artisan db:seed --class=DataPointsSeeder
Now, run the laravel 11 application using the following command.
php artisan serve
